Stripes
4 x panel stripes independently configurable for switcher, M/E, PREVIZ, or NDI™ output router operation
• Dynamic LCD crosspoint label displays
• Support for bank, layer and key delegation
• Support for multi-engine control
Crosspoints
72 x crosspoints per stripe (24 buttons with 3 delegate banks)
COMPs
Direct panel access to VMC1 Video Mix Engine COMP Bin presets
Macro
Macro mode and number pads supporting attachment and activation of user-configured macros
Media
2 x media player control keypad with player delegation and command buttons
MEM
Direct panel access to VMC1 Video Mix Engine switcher and M/E MEMs
T-Bars
4 x multi-mode T-Bars (1 per stripe) with dynamically variable illumination and support for BKGD video layer
and key layer delegation
• Fade
• Transition
• Fade to Black
• LiveSet™ Zoom
Joysticks
2 x multi-mode joysticks (3-axis) supporting stripe, layer and key delegation
• Position/Scale
• Rotate
• Crop
• LiveSet virtual camera control
• PTZ camera control
• Media player shuttle
NIC
1 Gigabit NIC
